CaterpillarCaterpillar
434E
Backhoe Loader
37 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight 4wd | 16,689 lb |
|---|---|
| Fuel Capacity | 38.4 gal |
| Hydraulic System Fluid Capacity | 10.1 gal |
| Cooling System Fluid Capacity | 4.3 gal |
| Turning Radius | 214 in |
| Transmission Fluid Capacity | 4.9 gal |
| Max Weight | 22,487 lb |
| Rear Axle Fluid Capacity | 4.4 gal |
| Front Axle Fluid Capacity | 3.0 gal |
Engine
| Engine Model | 3054C |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 94.0 hp |
| Net Power | 91.0 hp |
| Number of Cylinders | 4 |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 33.1 gal/min |
|---|---|
| Relief Valve Pressure | 227 psi |
| Pump Type | Variable-Flow Axial-Piston |
Dimensions
| Wheelbase | 88 in |
|---|---|
| Transport Width | 94 in |
| Transport Length | 229 in |
| Height to Top of Suspended Cab | 113 in |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Max Speed - Reverse | 24.9 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Caterpillar Power-Shuttle |
Backhoe
| Dig Depth | 196 in |
|---|---|
| Reach From Swivel | 221 in |
| Dig Depth - Extended | 236 in |
| Load Height - Extended | 168 in |
| Load Height | 148 in |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Clearance at Max Dump Height | 106 in |
| Bucket Breakout Force | 11,240 lb |
| Bucket Width | 89 in |
| Dig Depth | 4 in |
