CaterpillarCaterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Operating Weight 4wd | 16,066 lb |
|---|---|
| Fuel Capacity | 38.0 gal |
| Hydraulic System Fluid Capacity | 21.0 gal |
| Cooling System Fluid Capacity | 4.4 gal |
| Tire Size Front - 2wd / 4wd | 335/80R 18 XM37 / 12.5/80-18 NHS (10 ply) 1-3 super traction |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.0 gal |
| Turning Radius | 214 in |
| Transmission Fluid Capacity | 5.0 gal |
| Max Weight | 23,568 lb |
| Rear Axle Fluid Capacity | 4.4 gal |
| Front Axle Fluid Capacity | 2.0 gal |
Engine
| Engine Model | 3054C DIT |
|---|---|
| Displacement | 268 in³ |
| Gross Power | 101.0 hp |
| Net Power | 97.0 hp |
| Net Max Torque | 299 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 43.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,611 psi |
| Pump Type | variable-flow axial piston |
Dimensions
| Wheelbase | 88 in |
|---|---|
| Transport Width | 96 in |
| Transport Length | 291 in |
| Height to Top of Suspended Cab | 111 in |
Transmission
| Max Speed | 26.8 mph |
|---|---|
| Max Speed - Reverse | 26.8 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | power-shuttle |
Tires & Wheels
| Rear Tires Size | 19.5L-R24 XM37 / 21L-24 (16 ply) R4 ATU |
|---|
General Specifications
| Operating Weight lbs (kg) | 16,066 (7,287) — Starting 2011 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 15.4 (4.7) — Starting 2011 Model Year |
| Backhoe Loading Height ft. (m) | 13.0 (4.0) — Starting 2011 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 27 (43.5) — Starting 2011 Model Year |
| Loader SAE HP (kw) | 102 (76.1) — Starting 2011 Model Year |
| Loader Lift Capacity lbs. (kg) | 6,356 (2,883) — Starting 2011 Model Year |
| Loader Breakout Force lbs. (kg) | 10,225 (4,638) — Starting 2011 Model Year |
Backhoe
| Dig Depth | 186 in |
|---|---|
| Reach From Swivel | 239 in |
| Dig Depth - Extended | 234 in |
| Load Height - Extended | 179 in |
| Bucket Dig Force | 15,892 lb |
| Reach From Swivel - Extended | 285 in |
| Reach at Load Height - Extended | 115 in |
| Bucket Dig Force - Extended | 15,680 lb |
Loader
| Bucket Capacity | 1.40 yd³ |
|---|---|
| Clearance at Max Dump Height | 103 in |
| Bucket Breakout Force | 10,401 lb |
| Bucket Width | 8 in |
| Reach at Max Dump Height | 32 in |
| Dig Depth | 4 in |
