440

Specifications

18 data points

General Specifications specifications
Operating Weight lbs (kg)	21,544 (9,772) - 29,321 (13,300) — Starting 2024 Model Year
Operating Weight (Maximum)	29,321.00 lbs (13,299.80 kg) — Starting 2021 Model Year
Bucket Capacity (General Purpose)	1.75 cu yd — Starting 2021 Model Year
Max Digging Depth ft. (m)	15.5 (4.7) — Starting 2019 Model Year
Lift Capacity at Full Height	8,782.00 lbs (3,983.45 kg) — Starting 2023 Model Year
Backhoe Loading Height ft. (m)	13.5 (4.1) - 15.4 (4.7) — Starting 2024 Model Year
Travel Speed 4th Gear Fwd MPH (kmh)	24 (39) — Starting 2024 Model Year
Loader SAE HP (kw)	127 (95) — Starting 2025 Model Year
Loader Lift Capacity lbs. (kg)	8,782 (3,983) — Starting 2019 Model Year
Loader Breakout Force lbs. (kg)	13,560 (6,151) — Starting 2019 Model Year
Engine	C4.4 — Starting 2023 Model Year
Bucket Dig Force (Standard)	16,890.00 lbs ft (22,899.46 nm) — Starting 2023 Model Year
Digging Depth (Extendable Stick)	19.30 ft (5.88 m) — Starting 2023 Model Year
Digging Depth (Standard Stick)	15.60 ft (4.75 m) — Starting 2023 Model Year
Dump Height Max Angle	8.90 ft (2.71 m) — Starting 2023 Model Year
Loading Height (Standard)	14.00 ft (4.27 m) — Starting 2023 Model Year
Net	108 — Starting 2023 Model Year
Stick Dig Force (Standard)	10,199.00 lbs ft (13,827.80 nm) — Starting 2023 Model Year
