Caterpillar
Kubota
L48
Backhoe Loader
Specifications pending
1 / 5
Image 1 of 5
Specifications
18 data points
General Specifications
| Operating Weight lbs (kg) | 24,039 (10,904) - 29,321 (13,300) Starting 2024 Model Year |
|---|---|
| Operating Weight (Maximum) | 29,321.00 lbs (13,299.80 kg) Starting 2021 Model Year |
| Bucket Capacity (General Purpose) | 1.75 cu yd Starting 2021 Model Year |
| Max Digging Depth ft. (m) | 17.0 (5.2) Starting 2019 Model Year |
| Lift Capacity at Full Height | 8,886.00 lbs (4,030.63 kg) Starting 2021 Model Year |
| Backhoe Loading Height ft. (m) | 14.9 (4.5) - 17.3 (5.3) Starting 2024 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 25 (40) Starting 2019 Model Year |
| Loader SAE HP (kw) | 143 (106) Starting 2025 Model Year |
| Loader Lift Capacity lbs. (kg) | 8,886 (4,031) Starting 2019 Model Year |
| Loader Breakout Force lbs. (kg) | 13,560 (6,151) Starting 2019 Model Year |
| Engine | C4.4 Starting 2023 Model Year |
| Bucket Dig Force (Standard) | 17,784.00 lbs ft (24,111.55 nm) Starting 2023 Model Year |
| Digging Depth (Extendable Stick) | 21.10 ft (6.43 m) Starting 2021 Model Year |
| Digging Depth (Standard Stick) | 17.00 ft (5.18 m) Starting 2021 Model Year |
| Dump Height Max Angle | 9.00 ft (2.74 m) Starting 2021 Model Year |
| Loading Height (Standard) | 14.90 ft (4.54 m) Starting 2023 Model Year |
| Net | 134 Starting 2023 Model Year |
| Stick Dig Force (Standard) | 11,904.00 lbs ft (16,139.44 nm) Starting 2023 Model Year |
