Caterpillar
Tata Hitachi
EX3600-5
Mini Excavator
26 specifications
1 / 5
Image 1 of 5
Specifications
15 data points
Operating Specifications
| Fuel Capacity | 1,407.9 gal |
|---|
Engine
| Engine Model | 3516 EUI |
|---|---|
| Net Power | 1,470.0 hp |
Dimensions
| Height - Top of Cab | 294 in |
|---|---|
| Length of Track on Ground | 323 in |
| Upper Structure Ground Clearance | 97 in |
| Length of Tracks | 407 in |
| Height of Tracks | 90 in |
Undercarriage
| Max Travel Speed | 1.6 mph |
|---|---|
| Loading Shovel Operating Weight | 702,172 lb |
| Loading Shovel Shoe Width | 59 in |
| Loading Shovel Ground Pressure | 22 psi |
Loading Shovel
| Max Dig Depth | 150 in |
|---|---|
| Max Dig Reach | 395 in |
| Max Cutting Height | 592 in |
