CaterpillarCaterpillar
633E II
Scraper
91 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Fuel Capacity | 435.9 gal |
|---|---|
| Tire Size | 37.5R39 Radial (E-3) |
| Rated Load | 108,669 lb |
| Scraper Capacity - Heaped | 73.00 yd³ |
| Scraper Capacity - Struck | 58.70 yd³ |
| Top Speed - Loaded | 31.1 mph |
Engine
| Tractor Engine | Cat 3412E |
|---|---|
| Flywheel Power - Tractor/Scraper | 451 kW (605) / 328 kW (440) |
| Scraper Engine | 3408E |
Weights
| Operating Weight - Loaded - Approximate | 159,226 lb |
|---|---|
| Total Operating - empty | 151,810 lb |
| Total Operating - Loaded | 255,869 lb |
| Front Axle - empty | 92,605 lb |
| Rear Axle - empty | 59,205 lb |
| Front Axel - loaded | 130,494 lb |
| Rear Axle - loaded | 125,375 lb |
Dimensions
| Wheelbase | 391 in |
|---|---|
| Overall Length | 639 in |
| Overall Width | 172 in |
| Overall Height | 186 in |
Transmission
| Max Speed - Forward | 31.1 mph |
|---|---|
| Number of Forward Gears | 8 |
Bowl
| Heaped Capacity | 44.00 yd³ |
|---|---|
| Width of Cut | 152 in |
| Max Depth of Cut | 17 in |
| Rated Payload | 104,058 lb |
| Struck Capacity | 32.10 yd³ |
Scraper Engine
| Gross Power | 400.0 hp |
|---|---|
| Displacement | 1,099 in³ |
| Make | Caterpillar |
Tractor Engine
| Gross Power | 550.0 hp |
|---|---|
| Displacement | 1,648 in³ |
| Make | Caterpillar |
