Specifications
76 data points
Operating Specifications
| Fuel Capacity | 108.8 gal |
|---|---|
| Cooling System Fluid Capacity | 21.9 gal |
| Hydraulic System Fluid Capacity | 29.0 gal |
| Transmission Fluid Capacity | 9.2 gal |
Engine
| Engine Model | Cat C13 ACERT |
|---|---|
| Displacement | 763 in³ |
| Gross Power | 375.0 hp |
| Net Power | 367.0 hp |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 1,165 lb-ft |
| Stroke | 6 in |
| Bore | 5 in |
| Gross Power - SAE J1995 | 375.0 hp |
| Net Power - SAE J1349 | 367.0 hp |
| Net Power - ISO 14396 | 370.0 hp |
| Peak Engine Torque Gross (SAE J1995) | 1,579 lb-ft |
| Peak Engine Torque Speed | 1,200 rpm |
| No Engine De-rating Required Below | 150,000 in |
| Engine Model - U.S. EPA Tier 4 Final/EU Stage IV | Cat C13 ACERT |
| Peak Engine Torque Net (ISO 14396) | 1,564 lb-ft |
Weights
| Total Empty | 59,084 lb |
|---|---|
| Front Axle - empty | 34,811 lb |
| Total Loaded | 61,994 lb |
| Rear Axle - empty | 11,773 lb |
| Front Axle - loaded | 36,289 lb |
| Rear Axle - loaded | 42,031 lb |
| Center Axle - empty | 12,500 lb |
| Center Axle - loaded | 42,758 lb |
Transmission
| Number of Forward Gears | 6 |
|---|---|
| Number of Reverse Gears | 1 |
| Forward - 1 | 5.0 mph |
| Forward - 2 | 9.0 mph |
| Forward - 3 | 14.0 mph |
| Forward - 4 | 21.0 mph |
| Forward - 5 | 29.0 mph |
| Forward - 6 | 34.0 mph |
| Reverse - 1 | 6.0 mph |
Service Refill Capacities
| Cooling System | 21.9 gal |
|---|---|
| Fuel Tank | 108.8 gal |
| Engine Crankcase | 10.5 gal |
| Hydraulic System | 29.0 gal |
| Transmission | 9.2 gal |
| Output Transfer Gear Box | 6.3 gal |
| Final Drives/Differential | 35.7 gal |
| DEF Tank (ISO 2224-1) | 5.3 gal |
Dump
| Rated Payload | 62,000 lb |
|---|---|
| Capacity - Heaped | 22.10 yd³ |
| Capacity - Struck | 17.70 yd³ |
Standards
| Brakes | ISO 3450 - 2011 |
|---|---|
| Cab - ROPS | ISO 3471 - 2008 |
| Steering | ISO 5010 - 2007 |
| Cab - FOPS | ISO 3449 Level II - 2005 |
Steering System
| Lock to Lock | 4.75 seconds @ 60 rpm |
|---|
Operating Weights
| Total - Empty | 59,084 lb |
|---|---|
| Total - Rated Load | 61,994 lb |
| Center Axle - Empty | 12,500 lb |
| Center Axle - Loaded | 42,758 lb |
| Center Axle - Rated Load | 30,258 lb |
| Front Axle - Empty | 34,811 lb |
| Front Axle - Loaded | 36,289 lb |
| Front Axle - Rated Load | 1,478 lb |
| Rear Axle - Empty | 11,773 lb |
| Rear Axle - Loaded | 42,031 lb |
| Rear Axle - Rated Load | 30,258 lb |
| Total - Loaded | 121,078 lb |
Body Plate
| Body Plate Type | High Strength Brinell HB450 Wear Resistant Steel |
|---|
Ejector Cycle Times
| Eject Time | 12.0 s |
|---|---|
| Retract Time | 15.0 s |
Turning Circle
| Turning Dimensions - Aisle Width | 214 in |
|---|---|
| Turning Dimensions - Clearance Radius | 318 in |
| Turning Dimensions - Inside Radius | 148 in |
| Turning Dimensions - SAE Turning Radius | 294 in |
| Turning Dimensions - Steer Angle - Left/Right | 45 ° |
Body Capacities
| Heaped (SAE 2:1) | 22.10 yd³ |
|---|---|
| Struck | 17.70 yd³ |
Sound Levels
| Interior Cab | 76 dB(A) |
|---|
