Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
55 data points
Engine
| Stroke | 6 in |
|---|---|
| Gross Power - SAE J1995 | 375.0 hp |
| Net Power - SAE J1349 | 367.0 hp |
| Net Power - ISO 14396 | 370.0 hp |
| Peak Engine Torque Gross (SAE J1995) | 1,579 lb-ft |
| Peak Engine Torque Speed | 1,200 rpm |
| Peak Engine Torque Net (SAE J1349) | 1,564 lb-ft |
| No Engine De-rating Required Below | 150,000 in |
| Engine Model - U.S. EPA Tier 4 Final/EU Stage IV | Cat C13 ACERT |
| Peak Engine Torque Net (ISO 14396) | 1,564 lb-ft |
Transmission
| Forward - 1 | 5.0 mph |
|---|---|
| Forward - 2 | 9.0 mph |
| Forward - 3 | 14.0 mph |
| Forward - 4 | 21.0 mph |
| Forward - 5 | 29.0 mph |
| Forward - 6 | 34.0 mph |
| Reverse - 1 | 6.0 mph |
Service Refill Capacities
| Cooling System | 21.9 gal |
|---|---|
| Fuel Tank | 108.8 gal |
| Hydraulic System | 29.1 gal |
| Output Transfer Gear Box | 6.3 gal |
| DEF Tank | 5.2 gal |
| DEF Tank (ISO 2224-1) | 5.3 gal |
Dump
| Rated Payload | 68,343 lb |
|---|
Steering System
| Lock to Lock | 4.75 seconds @ 60 rpm |
|---|
Operating Weights
| Total - Empty | 52,305 lb |
|---|---|
| Total - Rated Load | 61,729 lb |
| Center Axle - Empty | 9,987 lb |
| Center Axle - Loaded | 37,236 lb |
| Center Axle - Rated Load | 27,249 lb |
| Front Axle - Empty | 32,882 lb |
| Front Axle - Loaded | 40,113 lb |
| Front Axle - Rated Load | 7,231 lb |
| Rear Axle - Empty | 9,436 lb |
| Rear Axle - Loaded | 36,685 lb |
| Rear Axle - Rated Load | 27,249 lb |
| Total - Loaded | 114,034 lb |
Body
| Plate thickness-Front | 0 in |
|---|
Body Plate
| Body Plate Type | High strength Brinell HB450 wear resistant steel |
|---|
Body Plate Thickness
| Base | 1 in |
|---|---|
| Side | 1 in |
Turning Circle
| Turning Dimensions - Aisle Width | 210 in |
|---|---|
| Turning Dimensions - Clearance Radius | 318 in |
| Turning Dimensions - Inside Radius | 153 in |
| Turning Dimensions - SAE Turning Radius | 294 in |
| Turning Dimensions - Steer Angle - Left/Right | 45 ° |
Body Capacities
| Heaped (SAE 2:1) | 22.99 yd³ |
|---|---|
| Struck | 17.40 yd³ |
| Tailgate Heaped SAE 2:1 | 24.60 yd³ |
| Tailgate Struck | 18.19 yd³ |
Body Hoist
| Lower Time | 8.0 s |
|---|---|
| Raise Time | 12.0 s |
Sound Levels
| Interior Cab | 76 dB(A) |
|---|
Wheel Base Length
| Long Wheel Base | 215 in |
|---|---|
| Standard Wheel Base | 157 in |
