Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
64 data points
Engine
| Engine Model | Cat C15 ACERT |
|---|---|
| Displacement | 926 in³ |
| Stroke | 7 in |
| Bore | 5 in |
| Gross Power - SAE J1995 | 452.0 hp |
| Net Power - SAE J1349 | 441.0 hp |
| Net Power - ISO 14396 | 447.0 hp |
| Peak Engine Torque Speed | 1,200 rpm |
| Peak Engine Torque Gross (SAE J1995) | 1,931 lb-ft |
| Peak Engine Torque Net (SAE J1349) | 1,887 lb-ft |
| No Engine De-rating Required Below | 120,000 in |
| Engine Model - U.S. EPA Tier 4 Final/EU Stage IV/Japan 2014 (Tier 4 Final)/Korea Tier 4 Final | Cat C15 ACERT |
Transmission
| Forward - 1 | 3.7 mph |
|---|---|
| Forward - 2 | 4.9 mph |
| Forward - 3 | 6.8 mph |
| Forward - 4 | 8.6 mph |
| Forward - 5 | 11.4 mph |
| Forward - 6 | 14.0 mph |
| Reverse - 1 | 3.9 mph |
| Forward - 7 | 19.3 mph |
| Reverse - 2 | 8.9 mph |
| Forward - 8 | 23.1 mph |
| Forward - 9 | 33.5 mph |
Service Refill Capacities
| Cooling System | 23.7 gal |
|---|---|
| Fuel Tank | 126.8 gal |
| Engine Crankcase | 10.6 gal |
| DEF Tank | 6.6 gal |
| Final Drive - Each | 1.3 gal |
| Axles - Each | 15.8 gal |
| Brake Cooling Tank | 17.7 gal |
| Steering/Hoist Hydraulic System | 36.9 gal |
| Transmission - OTG | 19.8 gal |
Dump
| Rated Payload | 79,366 lb |
|---|
Standards
| Brakes | ISO 3450-2011 |
|---|---|
| Cab - ROPS | ISO 3471-2008 |
| Steering | ISO 5010-2007 |
| Cab - FOPS | ISO 3449 Level II-2005 |
Steering System
| Lock to Lock | 4.6 seconds @ 60 rpm |
|---|
Operating Weights
| Total - Empty | 69,225 lb |
|---|---|
| Total - Rated Load | 72,091 lb |
| Center Axle - Empty | 13,977 lb |
| Center Axle - Loaded | 47,091 lb |
| Center Axle - Rated Load | 33,113 lb |
| Front Axle - Empty | 41,844 lb |
| Front Axle - Loaded | 47,708 lb |
| Front Axle - Rated Load | 5,864 lb |
| Rear Axle - Empty | 13,404 lb |
| Rear Axle - Loaded | 46,517 lb |
| Rear Axle - Rated Load | 33,113 lb |
| Total - Loaded | 141,316 lb |
Body Plate
| Body Plate Type | High strength Brinell HB450 wear resistant steel |
|---|
Turning Circle
| Turning Dimensions - Aisle Width | 221 in |
|---|---|
| Turning Dimensions - Clearance Radius | 331 in |
| Turning Dimensions - Inside Radius | 157 in |
| Turning Dimensions - SAE Turning Radius | 314 in |
Body Capacities
| Heaped (SAE 2:1) | 26.80 yd³ |
|---|---|
| Struck | 19.59 yd³ |
| Tailgate Heaped SAE 2:1 | 28.70 yd³ |
| Tailgate Struck | 20.30 yd³ |
Body Hoist
| Lower Time | 7.0 s |
|---|---|
| Raise Time | 12.0 s |
Sound Levels
| Interior Cab | 79 dB(A) |
|---|
Wheel Base Length
| Long Wheel Base | 228 in |
|---|---|
| Standard Wheel Base | 162 in |
