Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
84 data points
Operating Specifications
| Fuel Capacity | 145.3 gal |
|---|---|
| Cooling System Fluid Capacity | 23.7 gal |
| Hydraulic System Fluid Capacity | 36.9 gal |
| Transmission Fluid Capacity | 19.8 gal |
Engine
| Engine Model | Cat C18 ACERT |
|---|---|
| Displacement | 1,106 in³ |
| Gross Power | 511.0 hp |
| Net Power | 496.0 hp |
| Torque Measured @ | 1,200 rpm |
| Bore | 6 in |
| Stroke | 7 in |
| Gross Power - SAE J1995 | 511.0 hp |
| Net Power - SAE J1349 | 496.0 hp |
| Net Power - ISO 14396 | 504.0 hp |
| Peak Engine Torque Gross (SAE J1995) | 1,931 lb-ft |
| Peak Engine Torque Speed | 1,200 rpm |
| Peak Engine Torque Net (SAE J1349) | 1,887 lb-ft |
| No Engine De-rating Required Below | 120,000 in |
| Engine Model - U.S. EPA Tier 4 Final/EU Stage IV/Japan 2014 (Tier 4 Final)/Korea Tier 4 Final | Cat C18 ACERT |
Weights
| Total Empty | 73,634 lb |
|---|---|
| Front Axle - empty | 43,585 lb |
| Total Loaded | 90,389 lb |
| Rear Axle - empty | 14,749 lb |
| Front Axle - loaded | 56,593 lb |
| Rear Axle - loaded | 53,440 lb |
| Center Axle - empty | 15,300 lb |
| Center Axle - loaded | 53,991 lb |
Transmission
| Number of Forward Gears | 9 |
|---|---|
| Number of Reverse Gears | 2 |
| Forward - 1 | 3.8 mph |
| Forward - 2 | 5.0 mph |
| Forward - 3 | 7.0 mph |
| Forward - 4 | 8.8 mph |
| Forward - 5 | 11.6 mph |
| Forward - 6 | 14.2 mph |
| Reverse - 1 | 4.0 mph |
| Forward - 7 | 19.6 mph |
| Reverse - 2 | 9.1 mph |
| Forward - 8 | 23.5 mph |
| Forward - 9 | 34.0 mph |
Service Refill Capacities
| Cooling System | 23.7 gal |
|---|---|
| Fuel Tank | 145.3 gal |
| Engine Crankcase | 13.7 gal |
| DEF Tank | 6.6 gal |
| Final Drive - Each | 1.3 gal |
| Axles - Each | 15.8 gal |
| Brake Cooling Tank | 17.7 gal |
| Steering/Hoist Hydraulic System | 36.9 gal |
| Transmission - OTG | 19.8 gal |
Dump
| Raise Time | 12.0 s |
|---|---|
| Lower Time | 8.0 s |
| Capacity - Heaped | 32.70 yd³ |
| Capacity - Struck | 24.20 yd³ |
Standards
| Brakes | ISO 3450 2011 |
|---|---|
| Cab - ROPS | ISO 3471 2008 |
| Steering | ISO 5010 2007 |
| Cab - FOPS | ISO 3449 Level II 2005 |
Steering System
| Lock to Lock | 4.8 seconds @ 60 rpm |
|---|
Operating Weights
| Total - Empty | 73,634 lb |
|---|---|
| Total - Rated Load | 90,389 lb |
| Center Axle - Empty | 15,300 lb |
| Center Axle - Loaded | 53,991 lb |
| Center Axle - Rated Load | 38,691 lb |
| Front Axle - Empty | 43,585 lb |
| Front Axle - Loaded | 56,593 lb |
| Front Axle - Rated Load | 13,007 lb |
| Rear Axle - Empty | 14,749 lb |
| Rear Axle - Loaded | 53,440 lb |
| Rear Axle - Rated Load | 38,691 lb |
| Total - Loaded | 164,024 lb |
Body Plate
| Body Plate Type | High strength Brinell HB450 wear resistant steel |
|---|
Turning Circle
| Turning Dimensions - Aisle Width | 235 in |
|---|---|
| Turning Dimensions - Clearance Radius | 358 in |
| Turning Dimensions - Inside Radius | 174 in |
| Turning Dimensions - SAE Turning Radius | 340 in |
Body Capacities
| Heaped (SAE 2:1) | 32.70 yd³ |
|---|---|
| Struck | 24.20 yd³ |
| Tailgate Heaped SAE 2:1 | 34.70 yd³ |
| Tailgate Struck | 25.51 yd³ |
Body Hoist
| Lower Time | 8.0 s |
|---|---|
| Raise Time | 12.0 s |
Sound Levels
| Interior Cab | 79 dB(A) |
|---|
Wheel Base Length
| Long Wheel Base | 228 in |
|---|---|
| Standard Wheel Base | 181 in |
