Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Fuel Capacity | 185.0 gal |
|---|---|
| Tire Size | 24.00-R35 (E4) |
| Engine Oil Capacity | 18.0 gal |
| Cooling System Fluid Capacity | 40.0 gal |
| Steering System Fluid Capacity | 16.0 gal |
| Diff and Final Drive Fluid Capacity | 41.0 gal |
| Brake/Hoist System Fluid Capacity | 81.0 gal |
Engine
| Engine Model | 3412E |
|---|---|
| Displacement | 1,649 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 710.0 hp |
| Net Power | 671.0 hp |
| Max Torque | 2,533 lb-ft |
Weights
| Empty Weight | 66,500 lb |
|---|---|
| Loaded Weight | 219,000 lb |
| Weight Distribution Front - loaded | 33.3 % |
| Weight Distribution Rear - loaded | 66.7 % |
| Weight Distribution Front - empty | 47.3 % |
| Weight Distribution Rear - empty | 52.7 % |
Dimensions
| Ground Clearance | 26 in |
|---|---|
| Wheelbase | 166 in |
| Overall Length | 364 in |
| Overall Width | 176 in |
| Overall Height | 175 in |
| Dump Height | 348 in |
| Dump Ground Clearance | 26 in |
Transmission
| Max Speed | 41.1 mph |
|---|---|
| Number of Gears - Forward | 7 |
| Number of Gears - Reverse | 1 |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 119,609.9 gal |
|---|
Dump
| Rated Payload | 119,623 lb |
|---|---|
| Load Capacity - heaped | 46.09 yd³ |
| Load Capacity - Struck | 34.80 yd³ |
