Caterpillar
Komatsu
960E-1
Off-Highway Truck
35 specifications
1 / 5
Image 1 of 5
Specifications
92 data points
Operating Specifications
| Fuel Capacity | 499.9 gal |
|---|---|
| Tire Size | 33.00-R51 tires |
| Engine Oil Capacity | 24.0 gal |
| Cooling System Fluid Capacity | 100.0 gal |
| Hydraulic System Fluid Capacity | 169.4 gal |
| Operating Voltage | 24 V |
| Steering System Fluid Capacity | 31.0 gal |
| Diff and Final Drive Fluid Capacity | 115.0 gal |
| Brake/Hoist System Fluid Capacity | 89.0 gal |
| Top Speed - Loaded | 34.0 mph |
| Lower Time | 15.9 s |
| Raise Time | 15.2 s |
| Turning Circle - Clearance Diameter | 787 in |
Engine
| Engine Model | Cat 3512B-EUI |
|---|---|
| Displacement | 3,158 in³ |
| Power Measured @ | 1,750 rpm |
| Gross Power | 1,451.0 hp |
| Net Power | 1,348.0 hp |
| Number of Cylinders | 16 |
| Torque Measured @ | — |
| Make | Cat |
| Bore | 7 in |
| Stroke | 8 in |
| Gross Power - SAE J1995 | 1,450.0 hp |
| Rated Engine Speed | 169 rpm |
| Net Power - ISO 9249 | 1,348.0 hp |
| Net Power - SAE J1349 | 1,348.0 hp |
| Net Power - 80/1269/EEC | 1,348.0 hp |
| Net Power - Cat | 1,348.0 hp |
Weights
| Operating Weight | 550,000 lb |
|---|---|
| Operating Weight - Loaded | SAE J1511 OCT90 ISO 5010:1992 lbs |
| Front Axle - empty | — |
| Rear Axle - empty | — |
| Front Axle - loaded | — |
| Rear Axle - loaded | — |
| Empty Weight | 225,200 lb |
| Loaded Weight | 550,000 lb |
| Weight Distribution Front - loaded | 33.0 % |
| Weight Distribution Rear - loaded | 67.0 % |
| Weight Distribution Front - empty | 47.0 % |
| Weight Distribution Rear - empty | 53.0 % |
| Body Weight | 164,134 lb |
| Gross Machine Operating Weight (GMW) | SAE J1040 APR88 ISO 3471:1994 lbs |
Dimensions
| Ground Clearance | 40 in |
|---|---|
| Wheelbase | 204 in |
| Overall Length | 435 in |
| Overall Width | 247 in |
| Overall Height | 228 in |
| Dump Height | 443 in |
| Dump Ground Clearance | 52 in |
Transmission
| Max Speed | 34.0 mph |
|---|---|
| Transmission Type | Six-speed planetary |
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 1 |
| Forward - 1 | 7.5 mph |
| Forward - 2 | 10.2 mph |
| Forward - 3 | 13.8 mph |
| Forward - 4 | 18.6 mph |
| Forward - 5 | 25.2 mph |
| Forward - 6 | 34.0 mph |
| Reverse | 6.8 mph |
Drive System
| Drive Config | 4x2 |
|---|
Service Refill Capacities
| Cooling System | 100.0 gal |
|---|---|
| Steering System - Including Tank | 31.0 gal |
| Steering Tank | 24.0 gal |
| Brake Hoist System - Includes Tank | 169.0 gal |
| Torque Converter - Transmission System - Including Sump | 65.6 gal |
| Brake / Hoist / Fan Hydraulic Tank | 102.0 gal |
| Torque Converter - Transmission Sump | 164,116.1 gal |
| Fuel Tank - Standard | 499.9 gal |
Articulating/Rigid
| Articulating/Rigid | Rigid |
|---|
Dump
| Dump Angle | 49 ° |
|---|---|
| Raise Time | 15.2 s |
| Lower Time | 15.9 s |
| Load Capacity - heaped | 119.00 yd³ |
| Load Capacity - Struck | 95.99 yd³ |
Sound
| Sound Standards | ANSI/SAE J1166 MAY90 SAE J88 APR95 |
|---|
Approximate Weights - Flat Floor
| Body | 56,630 lb |
|---|---|
| Chassis | 164,134 lb |
Body Hoists
| Pump Flow - High Idle | 198.0 gal/min |
|---|---|
| Relief Valve Setting - Raise | 2,500 psi |
| Body Raise Time - High Idle | 15.2 s |
| Body Lower Time - Float | 16.2 s |
| Relief Valve Setting - Lower | 74 psi |
Final Drives
| Planetary Ratio | 10.83:1 |
|---|
ROPS
| ROPS/FOPS Standards | 46,865 |
|---|
Capacity - Flat Floor - 100% Fill Factor
| Struck | 95.99 yd³ |
|---|
Suspension
| Rear axle - Oscillation | 12 ° |
|---|
Approximate Weights - Dual Slope
| Gross Weight - Empty | 211,035 lb |
|---|---|
| Chassis | 164,134 lb |
Capacity - Dual Slope - 100% Fill Factor
| Struck | 73.99 yd³ |
|---|---|
| Heaped 2:1 (SAE) | 95.99 yd³ |
