Komatsu
Terex
MT3700AC
Off-Highway Truck
32 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Fuel Capacity | 1,400.0 gal |
|---|---|
| Tire Size | 56/80 R63 |
| Engine Oil Capacity | 90.1 gal |
| Cooling System Fluid Capacity | 190.0 gal |
| Hydraulic System Fluid Capacity | 350.1 gal |
| Operating Voltage | 24 V |
Engine
| Engine Model | SSDA18V170 |
|---|---|
| Displacement | 4,760 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 3,500.2 hp |
| Net Power | 3,346.0 hp |
| Number of Cylinders | 18 |
| Aspiration | 140 amps |
| Rated Engine Speed | 350 rpm |
Weights
| Empty Weight | 549,998 lb |
|---|---|
| Loaded Weight | 1,270,021 lb |
| Weight Distribution Front - loaded | 33.0 % |
| Weight Distribution Rear - loaded | 67.0 % |
| Weight Distribution Front - empty | 49.5 % |
| Weight Distribution Rear - empty | 50.5 % |
Dimensions
| Ground Clearance | 41 in |
|---|---|
| Wheelbase | 344 in |
| Overall Length | 615 in |
| Overall Width | 362 in |
| Overall Height | 291 in |
| Dump Height | 556 in |
| Dump Ground Clearance | 67 in |
Transmission
| Max Speed | 40.1 mph |
|---|---|
| Transmission Type | Auto ECPC |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 719,918.3 gal |
|---|
Dump
| Dump Angle | 45 ° |
|---|---|
| Raise Time | 24.0 s |
| Lower Time | 28.0 s |
| Load Capacity - heaped | 279.99 yd³ |
| Load Capacity - Struck | 194.90 yd³ |
