Specifications
41 data points
Operating Specifications
| Standard MSD Body (SAE 2:1) | 169.99 yd³ |
|---|
Engine
| Engine Model | 3516C - HD |
|---|---|
| Displacement | 4,766 in³ |
| Gross Power | 2,100.0 hp |
| Net Power | 1,969.0 hp |
| Make | Cat |
| Bore | 7 in |
| Stroke | 8 in |
| Gross Power - SAE J1995 | 2,100.0 hp |
Weights
| Operating Weight | 700,000 lb |
|---|---|
| Operating Weight - Loaded | SAE J1511 OCT90 ISO 5010:1992 lbs (0.00 kg) |
| Front Axle - empty | — |
| Rear Axle - empty | — |
| Front Axle - loaded | — |
| Rear Axle - loaded | — |
Transmission
| Forward - 1 | 7.8 mph |
|---|---|
| Forward - 2 | 10.6 mph |
| Forward - 3 | 14.4 mph |
| Forward - 4 | 19.4 mph |
| Forward - 5 | 26.3 mph |
| Forward - 6 | 35.5 mph |
| Reverse | 7.3 mph |
General Specifications
| Operating Weight lbs (kg) | 700,000 (317,515) — Starting 2019 Model Year |
|---|---|
| Engine type | Cat 3516C HD — Starting 2019 Model Year |
| Articulated/Rigid | R — Starting 2019 Model Year |
| Drive Configuration | 2WD — Starting 2019 Model Year |
| Rated Payload Tons (Metric Tons) | 181 (164.2) — Starting 2019 Model Year |
| Mfg. Model | 789D — Starting 2019 Model Year |
| Planetary Powershift Transmission | Auto — Starting 2019 Model Year |
Drive System
| Drive Config | 2WD |
|---|
Service Refill Capacities
| Cooling System | 192.0 gal |
|---|
Articulating/Rigid
| Articulating/Rigid | Rigid |
|---|
Dump
| Rated Payload | 399,036 lb |
|---|
Sound
| Sound Standards | Standards |
|---|
Body Hoists
| Pump Flow - High Idle | 193.0 gal/min |
|---|---|
| Relief Valve Setting - Raise | 2,500 psi |
| Body Raise Time - High Idle | 18.9 s |
Final Drives
| Planetary Ratio | 10.83:1 |
|---|
ROPS
| ROPS Standards | Standards |
|---|
Suspension
| Effective Cylinder Stroke - Rear | 4 in |
|---|---|
| Rear axle - Oscillation | 4 ° |
