Caterpillar
Komatsu
960E-1
Off-Highway Truck
35 specifications
1 / 5
Image 1 of 5
Specifications
54 data points
Operating Specifications
| Top Speed - Loaded | 37.3 mph |
|---|---|
| Nominal Payload Capacity | 500,000 lb |
| Turning Diameter - Front | 1,284 in |
Engine
| Engine Model | Cat C175-16 |
|---|---|
| Displacement | 5,187 in³ |
| Net Power | 2,478.0 hp |
| Make | Cat |
| Bore | 7 in |
| Stroke | 9 in |
| Torque Rise | — |
| Gross Power - SAE J1995 | 2,650.0 hp |
| Net Power - SAE J1349 | 2,478.0 hp |
Weights
| Operating Weight | 851,000 lb |
|---|---|
| Operating Weight - Loaded | SAE J15111 OCT90 ISO 5010:1992 lbs |
| Front Axle - empty | — |
| Rear Axle - empty | — |
| Front Axle - loaded | — |
| Rear Axle - loaded | — |
| Chassis Weight | 270,000 lb |
| Body Weight Range | — |
| Gross Machine Operating Weight (GMW) | ROPS (Rollover Protective Structure) for cab offered by Caterpillar meets ISO 3471:1994 ROPS criteria. lbs |
Transmission
| Forward - 1 | 8.0 mph |
|---|---|
| Forward - 2 | 10.8 mph |
| Forward - 3 | 14.8 mph |
| Forward - 4 | 19.9 mph |
| Forward - 5 | 27.1 mph |
| Forward - 6 | 37.3 mph |
| Reverse | 7.3 mph |
Tires & Wheels
| Standard Tires | 13,921 |
|---|
General Specifications
| Operating Weight lbs (kg) | 851,000 (386,007) Starting 2019 Model Year |
|---|---|
| Engine type | Cat C175-16 Starting 2019 Model Year |
| Articulated/Rigid | Rigid Starting 2024 Model Year |
| Drive Configuration | 2WD Starting 2019 Model Year |
| Rated Payload Tons (Metric Tons) | 256 (232( Starting 2021 Model Year |
| Mfg. Model | 793F Starting 2019 Model Year |
| Planetary Powershift Transmission | Auto Starting 2019 Model Year |
Drive System
| Drive Config | 2WD |
|---|
Service Refill Capacities
| Cooling System | 284.0 gal |
|---|---|
| Fuel Tank | 749.9 gal |
| Steering System - Including Tank | 77.0 gal |
| Brake Hoist System - Includes Tank | 347.0 gal |
| Fuel Tank - Standard | 1,299.9 gal |
| Differential - Final Drives | 82.0 gal |
| Crankcase | 82.0 gal |
Articulating/Rigid
| Articulating/Rigid | Rigid |
|---|
Dump
| Rated Payload | 500,449 lb |
|---|
Steering System
| Steering Standards | SAE J15111 OCT90 ISO 5010:1992 |
|---|
Sound
| Sound Standards | The operator sound pressure level measured according to work cycle procedures specified in ISO 6394 and 6396 is 76 dB(A) for cab offered by Caterpillar when properly installed and maintained and tested with doors and windows closed. |
|---|
Body Hoists
| Pump Flow - High Idle | 224.0 gal/min |
|---|---|
| Relief Valve Setting - Raise | 2,955 psi |
| Body Raise Time - High Idle | 19.0 s |
| Body Lower Time - Float | 20.0 s |
Final Drives
| Planetary Ratio | 0.667361111111111 |
|---|
Suspension
| Rear axle - Oscillation | 5 ° |
|---|
