Caterpillar
Komatsu
830E
Off-Highway Truck
32 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Top Speed - Loaded | 40.0 mph |
|---|---|
| Nominal Payload Capacity | 690,000 lb |
| Turning Circle - Clearance Diameter | 1,524 in |
| Turning Diameter - Front | 1,524 in |
Engine
| Engine Model | Cat C175-16 |
|---|---|
| Displacement | 5,187 in³ |
| Net Power | 3,188.0 hp |
| Make | Cat |
| Bore | 7 in |
| Stroke | 9 in |
| Torque Rise | — |
| Gross Power - SAE J1995 | 3,400.0 hp |
Weights
| Operating Weight | 1,257,000 lb |
|---|---|
| Operating Weight - Loaded | SAE J1511 OCT90 ISO 5010:1992 lbs (0.00 kg) |
| Front Axle - empty | — |
| Rear Axle - empty | — |
| Front Axle - loaded | — |
| Rear Axle - loaded | — |
Tires & Wheels
| Standard Tires | — |
|---|
Drive System
| Drive Config | 2WD |
|---|
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 134.2 gal |
|---|---|
| Cooling System | 291.0 gal |
| Fuel Tank | 949.9 gal |
| Steering System - Including Tank | 79.0 gal |
| Steering Tank | 55.5 gal |
| Brake Hoist System - Includes Tank | 396.3 gal |
| Torque Converter - Transmission Sump | 445,475.5 gal |
| Fuel Tank - Standard | 1,899.8 gal |
| Differential - Final Drives | 82.0 gal |
| Crankcase | 82.0 gal |
Articulating/Rigid
| Articulating/Rigid | Rigid |
|---|
Dump
| Rated Payload | 701,069 lb |
|---|
Sound
| Sound Standards | Standards |
|---|
Body Hoists
| Pump Flow - High Idle | 247.0 gal/min |
|---|---|
| Relief Valve Setting - Raise | 3,553 psi |
| Body Raise Time - High Idle | 19.0 s |
| Body Lower Time - Float | 20.0 s |
Final Drives
| Total Reduction Ratio | 690000 |
|---|
ROPS
| ROPS Standards | Standards |
|---|
Suspension
| Effective Cylinder Stroke - Rear | 6 in |
|---|---|
| Rear axle - Oscillation | 12 ° |
