Caterpillar
Komatsu
830E
Off-Highway Truck
32 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Engine
| Displacement | 6,469 in³ |
|---|---|
| Gross Power | 4,000.1 hp |
| Make | Cat |
| Stroke | 9 in |
| Bore | 7 in |
| Rated Engine Speed | — |
| Net Power - SAE J1349 | 3,795.1 hp |
Weights
| Operating Weight | 1,375,000 lb |
|---|---|
| Front Axle - empty | — |
| Rear Axle - empty | — |
| Front Axle - loaded | — |
| Rear Axle - loaded | — |
| Body Weight | 94,799 lb |
| Chassis Weight | 474,472 lb |
| Nominal Rated Payload | 884,053 lb |
Transmission
| Max Speed | 39.5 mph |
|---|---|
| Forward - 1 | 6.6 mph |
| Forward - 2 | 8.9 mph |
| Forward - 3 | 12.0 mph |
| Forward - 4 | 16.2 mph |
| Forward - 5 | 21.8 mph |
| Forward - 6 | 29.4 mph |
| Forward - 7 | 39.5 mph |
| Reverse | 7.4 mph |
Tires & Wheels
| Standard Tires | — |
|---|
General Specifications
| Operating Weight lbs (kg) | 1,375,000 (623,690) Starting 2019 Model Year |
|---|---|
| Engine type | Cat C175-20 Starting 2019 Model Year |
| Articulated/Rigid | Rigid Starting 2024 Model Year |
| Drive Configuration | 2WD Starting 2019 Model Year |
| Rated Payload Tons (Metric Tons) | 363 (329.3) Starting 2019 Model Year |
| Mfg. Model | 797F Starting 2019 Model Year |
| Planetary Powershift Transmission | Auto Starting 2019 Model Year |
Drive System
| Drive Config | 2WD |
|---|
Articulating/Rigid
| Articulating/Rigid | Rigid |
|---|
Dump
| Rated Payload | 884,053 lb |
|---|
