Caterpillar
Komatsu
WF450T-1
Landfill Compactor
16 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 52,364 lb |
|---|---|
| Fuel Capacity | 117.8 gal |
| Hydraulic System Fluid Capacity | 36.2 gal |
| Engine Oil Capacity | 9.0 gal |
| Cooling System Fluid Capacity | 14.5 gal |
| Transmission Fluid Capacity | 13.2 gal |
Engine
| Engine Model | 3176C ATAAC |
|---|---|
| Displacement | 629 in³ |
| Gross Power | 254.0 hp |
| Net Power | 240.0 hp |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 150 in |
| Wheelbase | 132 in |
Transmission
| Max Speed | 6.6 mph |
|---|---|
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Blades
| Blade Width | 144 in |
|---|---|
| Blade Height | 75 in |
Wheels
| Front Wheels Drum Diameter | 51 in |
|---|---|
| Front Wheels Drum Width | 40 in |
| Rear Wheels Drum Diameter | 51 in |
| Rear Wheels Drum Width | 40 in |
