CaterpillarCaterpillar
814F II
Wheel Dozer
62 specifications
1 / 5
Image 1 of 5
Specifications
76 data points
Operating Specifications
| Operating Weight | 63,325 lb |
|---|---|
| Fuel Capacity | 185.0 gal |
| Tire Size | 29.5-25 L-3 |
| Engine Oil Capacity | 9.0 gal |
| Front Diff Fluid Capacity | 23.8 gal |
| Rear Diff Fluid Capacity | 23.8 gal |
| Transmission Fluid Capacity | 16.4 gal |
| Cooling System Fluid Capacity | 21.9 gal |
| Axle Oscillation | 13 ° |
| Ground Clearance | 15 in |
Engine
| Engine Model | Cat C15 ACERT |
|---|---|
| Displacement | 928 in³ |
| Power Measured @ | 1,800 rpm |
| Engine Make | 2236 |
| Bore | 5 in |
| Stroke | 7 in |
| Net Power - ISO 9249 | 354.0 hp |
| Net Power - EEC 80/1269 | 354.0 hp |
| Flywheel Power | 354.0 hp |
| Cylinders | 6 |
| Net Power - SAE J1349 (JAN90) | 350.1 hp |
| Direct Drive - Gross Power | 401.0 hp |
| Direct Drive - Flywheel Power | 354.0 hp |
Weights
| Operating Weight | 63,325 lb |
|---|
Hydraulic System
| Relief Valve Setting | 3,500 psi |
|---|---|
| Lift Cylinder, Bore and Stroke | 120.65 mm x 915 mm (4.75 in x 36.0 in) |
| Steering Cylinder, Bore and Stroke | 114.3 mm x 576 mm (4.5 in x 22.7 in) |
| Left Tilt and Tip, Bore and Stroke | 133.75 mm x 255 mm (5.3 in x 10.0 in) |
| Right Tilt and Tip, Bore and Stroke | 152.4 mm x 255 mm (6 in x 10.0 in) |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 146 in |
| Wheelbase | 146 in |
| Wheel Base | 146 in |
| Length With Blade on Ground | 324 in |
| Height - Top of Hood | 104 in |
| Height - Top of Exhaust | 141 in |
| Ground Clearance - Bumper | 35 in |
| Centerline of Rear Axle to Hitch | 73 in |
| Centerline of Rear Axle to Edge of Bumper | 107 in |
| Height - Bottom of Ladder | 18 in |
Transmission
| Max Speed - Forward | 20.0 mph |
|---|---|
| Max Speed - Reverse | 22.7 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Number of Forward Speeds | 4 |
| Number of Reverse Speeds | 4 |
| Converter Drive - Forward 1 | 3.8 mph |
| Converter Drive - Forward 2 | 6.5 mph |
| Converter Drive - Forward 3 | 11.5 mph |
| Converter Drive - Reverse 1 | 4.3 mph |
| Converter Drive - Reverse 2 | 7.5 mph |
| Converter Drive - Reverse 3 | 13.0 mph |
| Converter Drive - Forward 4 | 20.0 mph |
Brakes & Steering
| Brakes | Meet SAE/ISO 3450 1996 |
|---|
Cab & Operator
| ROPS/FOPS | Meets SAE and ISO standards |
|---|---|
| Sound Performance Levels | Meet ANSI/SAE SAE and ISO standards |
| Cab | ROPS/FOPS is standard |
Tires & Wheels
| Standard Tire Size | 29.5RR25 XHA MX L3 |
|---|
Service Refill Capacities
| Differential - Final Drives - Front | 23.8 gal |
|---|---|
| Transmission | 16.4 gal |
| Cooling System | 21.9 gal |
| Crankcase | 9.0 gal |
| Fuel Tank - Standard | 185.0 gal |
| Hydraulic Tank | 23.2 gal |
| Fuel Tank | 185.0 gal |
Blades
| Blade Width | 178 in |
|---|---|
| Blade Height | 49 in |
| Straight Blade - Capacity | 14.79 yd³ |
| Straight Blade - Digging Depth | 17 in |
| Straight Blade - Height | 49 in |
| Straight Blade - Maximum Tilt | 47 in |
| Straight Blade - Overall Width | 17 in |
| Straight Blade - Ground Clearance | 43 in |
| Straight Blade - Total Operating Weight | 63,325 lb |
Axles
| Rear | Oscillating 13 degrees |
|---|---|
| Oscillating Rear | 13 |
