CaterpillarCaterpillar
814K
Wheel Dozer
37 specifications
1 / 5
Image 1 of 5
Specifications
62 data points
Operating Specifications
| Ground Clearance | 16 in |
|---|---|
| Turning Circle - With Blade | 56,441 in |
Engine
| Engine Model | Cat C9 ACERT |
|---|---|
| Displacement | 537 in³ |
| Bore | 4 in |
| Stroke | 6 in |
| Torque Rise | 30.0 % |
| Net Power - ISO 9249 | 235.0 hp |
| Net Power - EEC 80/1269 | 235.0 hp |
| Flywheel Power | 232.0 hp |
| Cylinders | 6 |
| Net Power - SAE J1349 (JAN90) | 232.0 hp |
Hydraulic System
| Relief Valve Setting | 2,255 psi |
|---|---|
| Lift Cylinder, Bore and Stroke | 120.62 mm x 913.9 mm 4.74 in x 35.98 in |
| Steering Cylinder, Bore and Stroke | 101.6 mm x 597 mm 3.99 in x 23.5 in |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 132 in |
| Wheel Base | 132 in |
| Length With Blade on Ground | 271 in |
| Height - Top of Hood | 94 in |
| Height - Top of Exhaust | 130 in |
| Ground Clearance - Bumper | 30 in |
| Centerline of Rear Axle to Hitch | 66 in |
| Centerline of Rear Axle to Edge of Bumper | 74 in |
| Height - Bottom of Ladder | 18 in |
Transmission
| Forward - 1 | 3.6 mph |
|---|---|
| Forward - 2 | 6.4 mph |
| Forward - 3 | 11.2 mph |
| Forward - 4 | 19.3 mph |
| Reverse - 1 | 4.1 mph |
| Reverse - 2 | 7.3 mph |
| Reverse - 3 | 12.7 mph |
| Number of Forward Speeds | 4 |
| Number of Reverse Speeds | 4 |
| Reverse - 4 | 21.8 mph |
Brakes & Steering
| Brakes | Meet OSHA regulations |
|---|
Cab & Operator
| ROPS/FOPS | Standard |
|---|---|
| Cab | Meets SAE and ISO standards |
Tires & Wheels
| Standard Tire Size | 26.5 R25 XHA MX L3 |
|---|---|
| Tires | L3 rock tread |
Service Refill Capacities
| Differential - Final Drives - Front | 17.1 gal |
|---|---|
| Transmission | 13.2 gal |
| Cooling System | 14.5 gal |
| Crankcase | 9.0 gal |
| Fuel Tank - Standard | 117.8 gal |
| Hydraulic Tank | 23.2 gal |
Blades
| Blade Capacity | 3.51 yd³ |
|---|---|
| Straight Blade - Capacity | 3.51 yd³ |
| Straight Blade - Digging Depth | 22 in |
| Straight Blade - Height | 43 in |
| Straight Blade - Maximum Tilt | 31 in |
| Straight Blade - Overall Width | 142 in |
| Maximum Lift Above Ground | 29 in |
| Moldboard - Length | 142 in |
| Straight Blade - Total Operating Weight | 47,869 lb |
| Blade Tilt Angle - Left | 8 ° |
| Blade Tilt Angle - Right | 5 ° |
| Blade Tip Angle - Back | 5 ° |
| Blade Tip Angle - Forward | 10 ° |
| Blade Tip Angle - Total | 52 ° |
Axles
| Front | Fixed |
|---|---|
| Rear | Oscillating 12 degrees |
