WF450T-1
Landfill Compactor
16 specifications
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Operating Weight | 81,498 lb |
|---|---|
| Fuel Capacity | 177.6 gal |
| Hydraulic System Fluid Capacity | 23.3 gal |
| Engine Oil Capacity | 9.0 gal |
| Cooling System Fluid Capacity | 21.7 gal |
| Transmission Fluid Capacity | 16.4 gal |
Engine
| Engine Model | Cat C15 ACERT |
|---|---|
| Displacement | 928 in³ |
| Gross Power | 401.0 hp |
| Net Power | 354.0 hp |
| Stroke | 7 in |
| Bore | 5 in |
| Torque Rise | 19.0 % |
| Flywheel Power | 354.0 hp |
Weights
| Operating Weight | 81,498 lb |
|---|
Hydraulic System
| Relief Valve Setting | 3,506 psi |
|---|---|
| Lift Cylinder Bore x Stroke | 120.65 mm 915 mm (4.74 in 36.02 in) |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 166 in |
| Wheelbase | 146 in |
| Width Over Wheels | 150 in |
Transmission
| Max Speed | 6.6 mph |
|---|---|
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
| Forward - 1 | 3.6 mph |
| Forward - 2 | 6.1 mph |
| Reverse - 1 | 4.1 mph |
| Reverse - 2 | 6.6 mph |
Brakes & Steering
| Standards | Meet OSHA SAE J1473 DEC84 ISO 3450:1985 standards |
|---|
Cab & Operator
| ROPS/FOPS | Meets SAE and ISO standards |
|---|
Service Refill Capacities
| Fuel Tank | 177.6 gal |
|---|---|
| Differential - Final Drives - Front | 23.8 gal |
| Differential - Final Drives - Rear | 23.8 gal |
| Transmission | 16.4 gal |
| Cooling System | 21.7 gal |
| Crankcase | 9.0 gal |
| Hydraulic Tank | 23.3 gal |
Blades
| Blade Width | 178 in |
|---|---|
| Blade Height | 75 in |
| Blade Capacity | 17.09 yd³ |
Wheels
| Front Wheels Drum Diameter | 60 in |
|---|---|
| Front Wheels Drum Width | 47 in |
| Rear Wheels Drum Diameter | 60 in |
| Rear Wheels Drum Width | 47 in |
Axles
| Front | Planetary - Fixed |
|---|
Sound Performance
| Standards | Meet ANSI/SAE and ISO standards |
|---|
