Caterpillar
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 18,607 lb |
|---|---|
| Fuel Capacity | 39.1 gal |
| Tire Size | 15.5-25 12 PR (L-2) |
| Hydraulic System Fluid Capacity | 19.6 gal |
| Static Tipping Weight | 29,520 lb |
Engine
| Engine Model | 3304 |
|---|---|
| Displacement | 427 in³ |
| Net Power | 80.0 hp |
Hydraulic System
| Raise Time | 6.0 s |
|---|---|
| Lower Time | 3.0 s |
| Dump Time | 1.2 s |
Dimensions
| Height - Top of Cab | 125 in |
|---|---|
| Reach at Max Lift and Dump | 30 in |
| Length with Bucket on Ground | 226 in |
Transmission
| Max Speed - Forward | 27.3 mph |
|---|---|
| Max Speed - Reverse | 14.5 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 1.20 yd³ |
|---|---|
| Dump Clearance at Max Raise | 109 in |
| Breakout Force | 8,020 lb |
| Bucket Width | 97 in |
General Specifications
| Net Power | 121.00 hp (90.23 kw) Starting 2023 Model Year |
|---|---|
| Operating Weight | 21,694 (9,843) Starting 2024 Model Year |
| Operating Weight lbs (kg) | 21,694 (9,843) Starting 2025 Model Year |
| Bucket Capacity | 1.7 - 2.5 (1.3 - 1.9) Starting 2024 Model Year |
| Bucket Capacity cu. yd. (cu m) | 1.7 - 2.5 (1.3 - 1.9) Starting 2025 Model Year |
| Engine type | Cat C3.6 Starting 2024 Model Year |
| Engine Power | 121 (90) Starting 2024 Model Year |
| Max Dump Height | 9.60 ft (2.93 m) Starting 2021 Model Year |
| OperatingWeight lbs. (kg) | 21,694 (9,843) Starting 2026 Model Year |
| Travel Speed(Fwd/Rev) | 25 / 12.5 mph Starting 2025 Model Year |
| Engine Power Net hp (kW) | 121 (90) Starting 2025 Model Year |
| Tip Load | 13,280 (6,026) Starting 2024 Model Year |
| Engine | C3.6 Starting 2023 Model Year |
| Breakout Force | 17,357.00 lbs ft (23,532.62 nm) Starting 2023 Model Year |
| Full-Turn Tipping Load | 12,848.00 lbs (5,827.76 kg) Starting 2021 Model Year |
| Travel Speed | 25 / 12.5 mph Starting 2024 Model Year |
| Tip Load lbs. (kg) | 13,280 (6,026) Starting 2025 Model Year |
| Rated Bucket Capacity | 2.2 cu yd Starting 2021 Model Year |
