Caterpillar
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Fuel Capacity | 51.6 gal |
|---|---|
| Hydraulic System Fluid Capacity | 42.3 gal |
| Engine Oil Fluid Capacity | 5.2 gal |
| Front Axle/Diff Fluid Capacity | 5.6 gal |
| Rear Axle/Diff Fluid Capacity | 5.6 gal |
| Cooling System Fluid Capacity | 8.5 gal |
| Transmission Fluid Capacity | 2.3 gal |
| Rated Bucket Capacity | 2.50 – 6.50 yd³ |
Engine
| Engine Model | Cat® C7.1 ACERT™ |
|---|---|
| Displacement | 428 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 140.9 hp |
| Net Power | 136.8 hp |
| Max Torque | 524 lb-ft |
Weights
| Operating Weight | 28,360 lb |
|---|
Transmission
| Number of Forward Gears | 4 |
|---|---|
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 6.61 yd³ |
|---|---|
| Dump Clearance at Max Raise | 113 in |
