W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
53 data points
Operating Specifications
| Operating Weight | 20,499 lb |
|---|---|
| Fuel Capacity | 39.7 gal |
| Tire Size | 15.5-25 12 PR (L-2) |
| Hydraulic System Fluid Capacity | 24.4 gal |
| Static Tipping Weight | 15,221 lb |
| Operating Voltage | 24 V |
| Turning Radius | 202 in |
| Engine Oil Fluid Capacity | 3.7 gal |
| Rear Axle Oscillation | 30 ° |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 6.7 gal |
| Rear Axle/Diff Fluid Capacity | 6.7 gal |
| Transmission Fluid Capacity | 9.0 gal |
Engine
| Engine Model | 3204 |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 104.6 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 40.2 gal/min |
|---|---|
| Raise Time | 5.9 s |
| Lower Time | 3.6 s |
| Dump Time | 1.6 s |
| Relief Valve Setting | 2,500 psi |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 114 in |
| Width Over Tires | 93 in |
| Reach at Max Lift and Dump | 40 in |
| Length with Bucket on Ground | 260 in |
| Hinge Pin - Max Height | 143 in |
Transmission
| Max Speed - Forward | 18.9 mph |
|---|---|
| Max Speed - Reverse | 20.1 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 2.00 yd³ |
|---|---|
| Bucket Capacity - struck | 1.80 yd³ |
| Dump Clearance at Max Raise | 109 in |
| Breakout Force | 24,235 lb |
| Bucket Width | 94 in |
General Specifications
| Operating Weight | 27,972 (12,688) Starting 2024 Model Year |
|---|---|
| Operating Weight lbs (kg) | 27,972 (12,688) Starting 2025 Model Year |
| Bucket Capacity | 2.5 - 6.5 (1.9 - 5) Starting 2024 Model Year |
| Bucket Capacity cu. yd. (cu m) | 2.5 - 6.5 (1.9 - 5) Starting 2025 Model Year |
| Engine type | Cat C7.1 Starting 2024 Model Year |
| Engine Power | 165 (123) Starting 2024 Model Year |
| OperatingWeight lbs. (kg) | 27,972 (12,688) Starting 2026 Model Year |
| Travel Speed(Fwd/Rev) | 25 / 25 mph Starting 2025 Model Year |
| Engine Power Net hp (kW) | 165 (123) Starting 2025 Model Year |
| Tip Load | 19,337 (8,771) Starting 2024 Model Year |
| Travel Speed | 25 / 25 mph Starting 2024 Model Year |
| Tip Load lbs. (kg) | 19,337 (8,771) Starting 2025 Model Year |
