Caterpillar
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 20,794 lb |
|---|---|
| Fuel Capacity | 39.7 gal |
| Tire Size | 17.5-25 12PR |
| Hydraulic System Fluid Capacity | 24.4 gal |
| Static Tipping Weight | 14,945 lb |
| Turning Radius | 221 in |
Engine
| Engine Model | 3204 |
|---|---|
| Displacement | 317 in³ |
| Gross Power | 110.0 hp |
Hydraulic System
| Raise Time | 6.0 s |
|---|---|
| Lower Time | 3.6 s |
| Dump Time | 1.7 s |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 127 in |
| Wheelbase | 114 in |
| Width Over Tires | 93 in |
| Reach at Max Lift and Dump | 40 in |
| Length with Bucket on Ground | 263 in |
| Hinge Pin - Max Height | 144 in |
Transmission
| Max Speed - Forward | 21.3 mph |
|---|---|
| Max Speed - Reverse | 22.9 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 2.30 yd³ |
|---|---|
| Bucket Capacity - struck | 1.90 yd³ |
| Dump Clearance at Max Raise | 109 in |
| Breakout Force | 22,143 lb |
| Bucket Width | 95 in |
