W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 20,499 lb |
|---|---|
| Fuel Capacity | 39.6 gal |
| Hydraulic System Fluid Capacity | 24.3 gal |
| Static Tipping Weight | 15,221 lb |
| Operating Voltage | 24 V |
| Turning Radius | 200 in |
| Engine Oil Fluid Capacity | 3.7 gal |
| Rear Axle Oscillation | 30 ° |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 6.6 gal |
| Rear Axle/Diff Fluid Capacity | 6.6 gal |
| Transmission Fluid Capacity | 9.0 gal |
Engine
| Engine Model | 3204 |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 104.6 hp |
| Number of Cylinders | 4 |
| Aspiration | TURBOCHARGED |
Hydraulic System
| Pump Flow Capacity | 40.2 gal/min |
|---|---|
| Raise Time | 5.9 s |
| Lower Time | 3.6 s |
| Dump Time | 1.6 s |
| Relief Valve Setting | 2,500 psi |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 125 in |
| Wheelbase | 113 in |
| Width Over Tires | 91 in |
| Reach at Max Lift and Dump | 39 in |
| Length with Bucket on Ground | 259 in |
| Hinge Pin - Max Height | 142 in |
Transmission
| Max Speed - Forward | 18.8 mph |
|---|---|
| Max Speed - Reverse | 20.1 mph |
| Transmission Type | POWERSHIFT |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
