Caterpillar
928H
- Operating Weight
- 27,699 lb
- Bucket Capacity - heaped
- 2.60 yd³
- Gross Power
- 160.0 hp
- Net Power
- 149.0 hp
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 27,699 lb |
|---|---|
| Fuel Capacity | 59.4 gal |
| Tire Size | 20.5 R25 L3 |
| Hydraulic System Fluid Capacity | 33.0 gal |
| Static Tipping Weight | 22,008 lb |
| Turning Radius | 228 in |
| Engine Oil Fluid Capacity | 4.0 gal |
| Front Axle/Diff Fluid Capacity | 6.9 gal |
| Rear Axle/Diff Fluid Capacity | 6.6 gal |
| Cooling System Fluid Capacity | 11.1 gal |
| Transmission Fluid Capacity | 9.1 gal |
| Rated Bucket Capacity | 3.00 yd³ |
Engine
| Engine Model | C6.6 |
|---|---|
| Displacement | 403 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 160.0 hp |
| Net Power | 149.0 hp |
| Number of Cylinders | 6 |
| Make | Cat |
Weights
| Operating Weight | 27,818 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 40.2 gal/min |
|---|---|
| Raise Time | 6.1 s |
| Lower Time | 2.8 s |
| Dump Time | 1.2 s |
| Relief Valve Setting | 3,755 psi |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 130 in |
| Wheelbase | 114 in |
| Width Over Tires | 102 in |
| Reach at Max Lift and Dump | 36 in |
| Length with Bucket on Ground | 285 in |
| Hinge Pin - Max Height | 152 in |
Transmission
| Max Speed - Forward | 23.4 mph |
|---|---|
| Max Speed - Reverse | 16.0 mph |
| Transmission Type | Standard transmission |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 2.60 yd³ |
|---|---|
| Bucket Capacity - struck | 2.20 yd³ |
| Dump Clearance at Max Raise | 114 in |
| Breakout Force | 25,844 lb |
| Bucket Width | 101 in |
