Caterpillar
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
63 data points
Operating Specifications
| Fuel Capacity | 59.5 gal |
|---|---|
| Tire Size | 20.5R25 |
| Hydraulic System Fluid Capacity | 33.1 gal |
| Operating Voltage | 24 V |
| Turning Radius | 207 in |
| Alternator Supplied Amperage | 80 A |
| Front Axle/Diff Fluid Capacity | 6.9 gal |
| Rear Axle/Diff Fluid Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 10.6 gal |
| Transmission Fluid Capacity | 9.2 gal |
| Engine Oil Capacity | 4.3 gal |
| Static Tipping Load - Bucket | 20,834 lb |
| Front Diff Fluid Capacity | 6.9 gal |
| Rear Diff Fluid Capacity | 6.7 gal |
| Static Tipping Load - Forks | 15,944 lb |
| Static Tipping Load - Material Handler | 8,212 lb |
| Static Tipping Load - Full Turn | 18,029 lb |
| Dump Clearance | 111 in |
Engine
| Displacement | 366 in³ |
|---|---|
| Power Measured @ | 2,300 rpm |
| Gross Power | 161.0 hp |
| Net Power | 150.2 hp |
| Number of Cylinders | 1 |
| Engine Make | Caterpillar |
| Bore | 4 in |
| Stroke | 5 in |
Weights
| Operating Weight | 28,725 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 58.2 gal/min |
|---|---|
| Raise Time | 5.0 s |
| Lower Time | 2.8 s |
| Dump Time | 1.7 s |
| Relief Valve Setting | 3,757 psi |
| Pump Type | variable-displacement axial piston |
Dimensions
| Height - Top of Cab | 130 in |
|---|---|
| Wheelbase | 115 in |
| Width Over Tires | 97 in |
| Length with Bucket on Ground | 311 in |
| Hinge Pin - Max Height | 159 in |
| Wheel Base | 110 in |
| Reach at Max Height and Dump | 43 in |
| Length w/ Bucket on Ground | 292 in |
| Dump Clearance at Max Lift | 115 in |
| Max Lift Height | 154 in |
| Fork Tine Length | 48 in |
| Length with out Forks on Ground | 302 in |
| Height - Top of Hood | 85 in |
| Hook Reach at Max Lift - standard | 88 in |
Transmission
| Max Speed - Forward | 38.0 mph |
|---|---|
| Max Speed - Reverse | 24.0 mph |
| Transmission Type | countershaft |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
| Forward - 1 | 4.5 mph |
| Reverse - 1 | 4.5 mph |
Bucket
| Bucket Capacity - heaped | 2.80 yd³ |
|---|---|
| Bucket Capacity - struck | 2.30 yd³ |
| Breakout Force | 30,349 lb |
| Bucket Capacities | 6.50 yd³ |
Service Refill Capacities
| Cooling System | 10.6 gal |
|---|---|
| Transmission | 9.1 gal |
| Crankcase | 4.2 gal |
| Hydraulic Tank | 18.5 gal |
| Hydraulic System - Including Tank | 33.0 gal |
