Caterpillar
931C Series II
- Operating Weight
- 17,741 lb
- Bucket Capacity - heaped
- 1.10 yd³
- Bucket Capacity - struck
- 0.90 yd³
- Net Power
- 69.8 hp
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight | 17,741 lb |
|---|---|
| Bucket Capacity - heaped | 1.10 yd³ |
| Bucket Capacity - struck | 0.90 yd³ |
| Max Speed | 7.0 mph |
| Fuel Capacity | 30.7 gal |
| Static Tipping Load | 10,792 lb |
| Breakout Force Bucket | 14,270 lb |
| Cooling System Fluid Capacity | 5.3 gal |
| Hydraulic System Fluid Capacity | 15.1 gal |
| Final Drive Fluid Capacity - each | 2.2 gal |
| Engine Oil Capacity | 3.2 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | 3204 |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 69.8 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 22.7 gal/min |
|---|---|
| Lower Time | 3.1 s |
| Raise Time | 6.0 s |
| Relief Valve Pressure | 2,500 psi |
| Dump Time | 2.7 s |
| Pump Type | single-section gear |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 106 in |
| Width to Outside of Tracks | 71 in |
| Length with Bucket on Ground | 163 in |
| Reach at Dump Height | 33 in |
| Clearance at Full Height and Dump | 103 in |
| Length to Front of Track | 111 in |
Undercarriage
| Length of Track on Ground | 76 in |
|---|---|
| Track Gauge | 56 in |
| Track Shoe Width | 14 in |
| Ground Pressure | 9 psi |
| Number of Track Rollers per Side | 5 |
| Ground Contact Area | 2,093 in³ |
| Number of Shoes per Side | 37 |
