Caterpillar
935C Series II
- Operating Weight
- 19,310 lb
- Bucket Capacity - heaped
- 1.40 yd³
- Bucket Capacity - struck
- 1.10 yd³
- Net Power
- 80.0 hp
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 19,310 lb |
|---|---|
| Bucket Capacity - heaped | 1.40 yd³ |
| Bucket Capacity - struck | 1.10 yd³ |
| Max Speed | 6.6 mph |
| Fuel Capacity | 30.7 gal |
| Static Tipping Load | 12,796 lb |
| Breakout Force Bucket | 15,098 lb |
| Hydraulic System Fluid Capacity | 15.1 gal |
Engine
| Engine Model | 3204 |
|---|---|
| Displacement | 317 in³ |
| Net Power | 80.0 hp |
Hydraulic System
| Lower Time | 3.5 s |
|---|---|
| Raise Time | 6.3 s |
| Dump Time | 2.2 s |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 106 in |
| Width to Outside of Tracks | 71 in |
| Length with Bucket on Ground | 170 in |
| Reach at Dump Height | 35 in |
| Clearance at Full Height and Dump | 102 in |
Undercarriage
| Length of Track on Ground | 76 in |
|---|---|
| Track Gauge | 56 in |
| Track Shoe Width | 14 in |
| Ground Pressure | 9 psi |
| Number of Track Rollers per Side | 5 |
| Ground Contact Area | 2,093 in³ |
