Caterpillar
Komatsu
W60
Wheel Loader
25 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 28,500 lb |
|---|---|
| Fuel Capacity | 53.1 gal |
| Tire Size | 20.5-25 12PR(L-2) |
| Hydraulic System Fluid Capacity | 41.0 gal |
| Static Tipping Weight | 21,451 lb |
Engine
| Engine Model | 3304T |
|---|---|
| Displacement | 427 in³ |
| Net Power | 130.0 hp |
Hydraulic System
| Raise Time | 6.2 s |
|---|---|
| Lower Time | 3.1 s |
| Dump Time | 1.8 s |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 131 in |
| Width Over Tires | 96 in |
| Reach at Max Lift and Dump | 30 in |
| Length with Bucket on Ground | 244 in |
| Hinge Pin - Max Height | 146 in |
Transmission
| Max Speed - Forward | 22.4 mph |
|---|---|
| Max Speed - Reverse | 26.5 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 2.11 yd³ |
|---|---|
| Dump Clearance at Max Raise | 111 in |
| Breakout Force | 10,320 lb |
| Bucket Width | 97 in |
General Specifications
| Net Power | 251.00 hp (187.17 kw) Starting 2023 Model Year |
|---|---|
| Operating Weight | 42,421 (19,242) Starting 2024 Model Year |
| Operating Weight lbs (kg) | 42,421 (19,242) Starting 2025 Model Year |
| Bucket Capacity | 3.75 - 5.75 (2.9 - 4.4) Starting 2024 Model Year |
| Bucket Capacity cu. yd. (cu m) | 3.75 - 5.75 (2.9 - 4.4) Starting 2025 Model Year |
| Engine type | Cat C7.1 Starting 2024 Model Year |
| Engine Power | 231 (172) Starting 2024 Model Year |
| OperatingWeight lbs. (kg) | 42,421 (19,242) Starting 2026 Model Year |
| Travel Speed(Fwd/Rev) | 24.5 / 16 mph Starting 2025 Model Year |
| Engine Power Net hp (kW) | 231 (172) Starting 2025 Model Year |
| Tip Load | 26,369 (11,961) Starting 2024 Model Year |
| Engine | C7.1 Starting 2023 Model Year |
| Breakout Force | 40,690.00 lbs ft (55,167.50 nm) Starting 2023 Model Year |
| Full-Turn Tipping Load | 26,369.00 lbs (11,960.79 kg) Starting 2023 Model Year |
| Travel Speed | 24.5 / 16 mph Starting 2024 Model Year |
| Tip Load lbs. (kg) | 26,369 (11,961) Starting 2025 Model Year |
