Komatsu
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 17,218 lb |
|---|---|
| Fuel Capacity | 36.8 gal |
| Tire Size | 14.00-24-12PR (L-2) |
| Static Tipping Weight | 12,765 lb |
| Turning Radius | 204 in |
| Cooling System Fluid Capacity | 8.8 gal |
Engine
| Engine Model | 6D105 |
|---|---|
| Displacement | 396 in³ |
| Gross Power | 102.0 hp |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 115 in |
| Wheelbase | 101 in |
| Width Over Tires | 88 in |
| Reach at Max Lift and Dump | 40 in |
| Length with Bucket on Ground | 227 in |
| Hinge Pin - Max Height | 137 in |
Transmission
| Max Speed - Forward | 23.7 mph |
|---|---|
| Max Speed - Reverse | 23.8 mph |
| Transmission Type | full powershift countershaft type full soft shift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 1.90 yd³ |
|---|---|
| Dump Clearance at Max Raise | 108 in |
| Breakout Force | 16,560 lb |
| Bucket Width | 95 in |
