John Deere
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
45 data points
Operating Specifications
| Operating Weight | 13,404 lb |
|---|---|
| Fuel Capacity | 22.0 gal |
| Tire Size | 405/ 70R20 |
| Hydraulic System Fluid Capacity | 21.1 gal |
| Static Tipping Weight | 10,241 lb |
| Operating Voltage | 12 V |
| Turning Radius | 149 in |
| Engine Oil Fluid Capacity | 3.0 gal |
| Rear Axle Oscillation | 20 ° |
| Alternator Supplied Amperage | 65 A |
| Front Axle/Diff Fluid Capacity | 2.0 gal |
| Rear Axle/Diff Fluid Capacity | 1.8 gal |
| Cooling System Fluid Capacity | 3.2 gal |
| Rated Bucket Capacity | 1.40 yd³ |
Engine
| Engine Model | 5030T |
|---|---|
| Displacement | 186 in³ |
| Power Measured @ | 2,800 rpm |
| Net Power | 73.0 hp |
| Number of Cylinders | 5 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Make | John Deere |
| Torque Rise | 42.4 % |
Weights
| Operating Weight | 13,404 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 25.0 gal/min |
|---|---|
| Raise Time | 5.3 s |
| Lower Time | 4.5 s |
| Dump Time | 1.6 s |
| Relief Valve Setting | 2,750 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 182 in |
|---|---|
| Height - Top of Cab | 110 in |
| Wheelbase | 90 in |
| Width Over Tires | 354 in |
| Length with Bucket on Ground | 241 in |
| Hinge Pin - Max Height | 133 in |
Transmission
| Max Speed - Forward | 18.6 mph |
|---|---|
| Max Speed - Reverse | 18.6 mph |
| Transmission Type | Hydraulic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.40 yd³ |
|---|---|
| Dump Clearance at Max Raise | 133 in |
| Breakout Force | 12,364 lb |
| Bucket Width | 1,039 in |
