Hitachi
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 17,251 lb |
|---|---|
| Fuel Capacity | 37.0 gal |
| Tire Size | 15.5x25 |
| Hydraulic System Fluid Capacity | 15.9 gal |
| Static Tipping Weight | 12,963 lb |
| Operating Voltage | 24 V |
| Turning Radius | 211 in |
| Engine Oil Fluid Capacity | 4.0 gal |
| Rear Axle Oscillation | 22 ° |
| Alternator Supplied Amperage | 40 A |
| Front Axle/Diff Fluid Capacity | 4.5 gal |
| Rear Axle/Diff Fluid Capacity | 4.5 gal |
| Cooling System Fluid Capacity | 5.9 gal |
Engine
| Engine Model | W04DT |
|---|---|
| Displacement | 245 in³ |
| Power Measured @ | 2,300 rpm |
| Net Power | 108.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,700 rpm |
Hydraulic System
| Pump Flow Capacity | 37.0 gal/min |
|---|---|
| Raise Time | 5.3 s |
| Lower Time | 3.1 s |
| Dump Time | 1.1 s |
| Relief Valve Setting | 3,130 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 104 in |
| Width Over Tires | 93 in |
| Reach at Max Lift and Dump | 42 in |
| Length with Bucket on Ground | 251 in |
| Hinge Pin - Max Height | 139 in |
Transmission
| Max Speed - Forward | 21.4 mph |
|---|---|
| Max Speed - Reverse | 21.4 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.90 yd³ |
|---|---|
| Bucket Capacity - struck | 1.60 yd³ |
| Dump Clearance at Max Raise | 106 in |
| Breakout Force | 19,131 lb |
