CaterpillarCaterpillar
933C LGP
Crawler Loader
38 specifications
Caterpillar
955K
- Operating Weight
- 28,000 lb
- Bucket Capacity - heaped
- 1.80 yd³
- Bucket Capacity - struck
- 1.50 yd³
- Net Power
- 115.0 hp
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 28,000 lb |
|---|---|
| Bucket Capacity - heaped | 1.80 yd³ |
| Bucket Capacity - struck | 1.50 yd³ |
| Max Speed | 7.0 mph |
| Fuel Capacity | 57.1 gal |
| Cooling System Fluid Capacity | 11.1 gal |
| Hydraulic System Fluid Capacity | 25.9 gal |
| Final Drive Fluid Capacity - each | 2.6 gal |
| Engine Oil Capacity | 5.0 gal |
Engine
| Engine Model | D330 |
|---|---|
| Displacement | 427 in³ |
| Power Measured @ | 2,185 rpm |
| Net Power | 115.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 90 in |
| Width to Outside of Tracks | 81 in |
| Length with Bucket on Ground | 198 in |
| Clearance at Full Height and Dump | 115 in |
| Reach at Dump Height | 65 in |
| Length to Front of Track | 132 in |
Undercarriage
| Length of Track on Ground | 93 in |
|---|---|
| Track Gauge | 66 in |
| Track Shoe Width | 15 in |
| Number of Track Rollers per Side | 6 |
| Ground Contact Area | 2,760 in³ |
| Number of Shoes per Side | 41 |
