Caterpillar
Volvo
L60H
Wheel Loader
55 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 44,551 lb |
|---|---|
| Fuel Capacity | 80.4 gal |
| Tire Size | 26.5-25 14PR |
| Hydraulic System Fluid Capacity | 54.2 gal |
| Static Tipping Weight | 30,547 lb |
| Turning Radius | 281 in |
Engine
| Engine Model | 3306 |
|---|---|
| Displacement | 641 in³ |
| Gross Power | 216.0 hp |
Hydraulic System
| Raise Time | 7.1 s |
|---|---|
| Lower Time | 2.4 s |
| Dump Time | 2.0 s |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 142 in |
| Wheelbase | 132 in |
| Width Over Tires | 119 in |
| Reach at Max Lift and Dump | 52 in |
| Length with Bucket on Ground | 324 in |
| Hinge Pin - Max Height | 19 in |
Transmission
| Max Speed - Forward | 23.8 mph |
|---|---|
| Max Speed - Reverse | 27.1 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 4.80 yd³ |
|---|---|
| Bucket Capacity - struck | 4.20 yd³ |
| Dump Clearance at Max Raise | 118 in |
| Breakout Force | 41,918 lb |
| Bucket Width | 121 in |
