Caterpillar
Volvo
L180C
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 100,703 lb |
|---|---|
| Fuel Capacity | 174.1 gal |
| Hydraulic System Fluid Capacity | 78.0 gal |
| Static Tipping Weight | 67,889 lb |
| Breakout Force | 129,661 lb |
| Static Tipping Load - Full Turn | 80,432 lb |
| Dump Clearance | 167 in |
Engine
| Engine Model | Cat 3408E |
|---|---|
| Displacement | 1,099 in³ |
| Gross Power | 675.0 hp |
Hydraulic System
| Raise Time | 7.9 s |
|---|---|
| Lower Time | 4.0 s |
| Dump Time | 3.3 s |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 163 in |
| Width Over Tires | 139 in |
| Reach at Max Lift and Dump | 64 in |
| Length with Bucket on Ground | 431 in |
Transmission
| Max Speed - Forward | 21.9 mph |
|---|---|
| Max Speed - Reverse | 14.7 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 6.61 yd³ |
|---|---|
| Bucket Capacity - struck | 4.09 yd³ |
| Dump Clearance at Max Raise | 127 in |
| Breakout Force | 82,282 lb |
| Bucket Width | 149 in |
| Maximum Bucket Capacity | 9.00 yd³ |
Service Refill Capacities
| Fuel Tank | 252.0 gal |
|---|
Hydraulic Cycle Times
| Raise | 7.9 s |
|---|
