CaterpillarCaterpillar
993K
Wheel Loader
96 specifications
1 / 5
Image 1 of 5
Specifications
76 data points
Operating Specifications
| Operating Weight | 417,430 lb |
|---|---|
| Bucket Capacity Range | 15-31 m3 19.5-41 yd3 |
| Fuel Capacity | 1,199.3 gal |
| Hydraulic System Fluid Capacity | 236.5 gal |
| Static Tipping Weight | 279,454 lb |
| Articulation Angle | 40 ° |
| Rated Payload | 76,000 lb |
| Cat Truck Match - High Lift | 789C 793C |
| Cat Truck Match - Standard | 785C 789C |
| Rated Payload - High Lift | 68,000 lb |
| Rated Payload - Standard | 76,000 lb |
Engine
| Engine Model | Cat 3516B EUI |
|---|---|
| Displacement | 4,221 in³ |
| Net Power | 1,250.0 hp |
| Stroke | 8 in |
| Bore | 7 in |
| Net Power - ISO 9249 | 1,375.0 hp |
| Net Power - SAE J1349 | 1,361.0 hp |
| Net Power - EEC 80/1269 | 1,375.0 hp |
Hydraulic System
| Raise Time | 12.5 s |
|---|---|
| Lower Time | 4.0 s |
| Dump Time | 3.4 s |
Dimensions
| Overall Length | 661 in |
|---|---|
| Width Over Tires | 215 in |
| Reach at Max Lift and Dump | 81 in |
| Length with Bucket on Ground | 655 in |
| Reach at Maximum Lift/Dump | 89 in |
| Height - Top of Exhaust | 272 in |
| Wheel Base Length | 252 in |
| Hinge Pin Height at Full Lift | 322 in |
Transmission
| Max Speed - Forward | 14.6 mph |
|---|---|
| Max Speed - Reverse | 16.1 mph |
| Transmission Type | Cat planetary power shift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
| Forward - 1 | 4.6 mph |
| Reverse - 1 | 5.0 mph |
| Forward - 2 | 8.0 mph |
| Reverse - 2 | 8.9 mph |
| Forward - 3 | 14.1 mph |
| Reverse - 3 | 15.5 mph |
Bucket
| Bucket Capacity - heaped | 18.40 yd³ |
|---|---|
| Bucket Capacity - struck | 14.60 yd³ |
| Dump Clearance at Max Raise | 229 in |
| Breakout Force | 237,825 lb |
| Bucket Width | 223 in |
| Bucket Capacities | 41.00 yd³ |
| Maximum Bucket Capacity | 41.00 yd³ |
Service Refill Capacities
| Cooling System | 129.0 gal |
|---|---|
| Transmission | 92.0 gal |
| Crankcase | 75.5 gal |
| Fuel Tank | 1,225.9 gal |
| Differential - Final Drives - Front | 164.1 gal |
| Differential - Final Drives - Rear | 164.1 gal |
Axles
| Front | Fixed |
|---|---|
| Rear | Trunnion |
| Maximum Single-Wheel Rise and Fall | 27 in |
| Oscillation Angle | 10 ° |
Hydraulic Cycle Times
| Raise | 12.5 s |
|---|---|
| Dump | 3.4 s |
| Total Hydraulic Cycle Time | 19.9 s |
| Rack Back | 6.0 s |
Hydraulic System - Lift/Tilt
| Lift Cylinder - Bore | 13 in |
|---|---|
| Lift Cylinder - Stroke | 65 in |
| Lift/Tilt System - Circuit | Closed |
| Relief Valve Setting - Lift/Tilt | 4,408 psi |
| Lift/Tilt System - Pump | Piston fixed displacement |
| Tilt Cylinder - Bore | 11 in |
| Tilt Cylinder - Stroke | 45 in |
| Cylinders - Lift/Tilt | Double-acting |
| Number of Lift Cylinders | 2 |
| Number of Tilt Cylinders | 2 |
| Number of Lift/Tilt Pumps | 3 |
Hydraulic System - Steering
| Steering System - Circuit | Closed |
|---|---|
| Steering System - Pump | Piston variable displacement |
| Relief Valve Setting - Steering | 4,495 psi |
