A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Fuel Capacity | 132.0 gal |
|---|---|
| Tire Size | 265 x R25 Radials |
| Engine Oil Capacity | 10.0 gal |
| Cooling System Fluid Capacity | 20.0 gal |
| Hydraulic System Fluid Capacity | 38.3 gal |
| Transmission Fluid Capacity | 17.7 gal |
Engine
| Engine Model | C15 ACERT |
|---|---|
| Displacement | 928 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 408.0 hp |
| Net Power | 377.0 hp |
Weights
| Total Empty | 66,150 lb |
|---|---|
| Front Axle - empty | 44,651 lb |
| Total Loaded | 132,300 lb |
| Rear Axle - empty | 21,499 lb |
| Front Axle - loaded | 58,477 lb |
| Rear Axle - loaded | 73,823 lb |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Wheelbase | 205 in |
| Overall Length | 4,001 in |
| Overall Width | 107 in |
| Overall Height | 101 in |
| Dump Height | 221 in |
| Dump Ground Clearance | 23 in |
Transmission
| Max Speed | 25.4 mph |
|---|---|
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 1 |
Dump
| Rated Payload | 66,150 lb |
|---|---|
| Dump Angle | 65 ° |
| Raise Time | 10.5 s |
| Lower Time | 11.2 s |
| Capacity - Heaped | 18.80 yd³ |
