Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Fuel Capacity | 201.8 gal |
|---|---|
| Tire Size | 29.5 x R29 |
| Engine Oil Capacity | 16.9 gal |
| Cooling System Fluid Capacity | 22.5 gal |
| Hydraulic System Fluid Capacity | 70.3 gal |
| Transmission Fluid Capacity | 15.9 gal |
Engine
| Engine Model | C18 ACERT |
|---|---|
| Displacement | 1,105 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 587.0 hp |
| Net Power | 556.0 hp |
Weights
| Total Empty | 88,184 lb |
|---|---|
| Front Axle - empty | 60,847 lb |
| Total Loaded | 187,393 lb |
| Rear Axle - empty | 27,337 lb |
| Front Axle - loaded | 85,451 lb |
| Rear Axle - loaded | 101,942 lb |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Wheelbase | 220 in |
| Overall Length | 442 in |
| Overall Width | 119 in |
| Overall Height | 120 in |
| Dump Height | 251 in |
| Dump Ground Clearance | 26 in |
Transmission
| Max Speed | 32.3 mph |
|---|---|
| Number of Forward Gears | 7 |
| Number of Reverse Gears | 2 |
Dump
| Raise Time | 16.0 s |
|---|---|
| Lower Time | 21.0 s |
| Capacity - Heaped | 27.90 yd³ |
