Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Fuel Capacity | 201.9 gal |
|---|---|
| Tire Size | 25x65 R33 |
| Engine Oil Capacity | 17.0 gal |
| Cooling System Fluid Capacity | 22.5 gal |
| Hydraulic System Fluid Capacity | 70.3 gal |
| Transmission Fluid Capacity | 15.9 gal |
Engine
| Engine Model | C18 ATTAAC |
|---|---|
| Displacement | 1,107 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 650.0 hp |
| Net Power | 617.0 hp |
Weights
| Total Empty | 103,617 lb |
|---|---|
| Front Axle - empty | 69,004 lb |
| Rear Axle - empty | 34,612 lb |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 233 in |
| Overall Length | 455 in |
| Overall Width | 132 in |
| Overall Height | 198 in |
Transmission
| Max Speed | 26.9 mph |
|---|---|
| Number of Forward Gears | 7 |
| Number of Reverse Gears | 2 |
Dump
| Raise Time | 11.0 s |
|---|---|
| Lower Time | 4.0 s |
| Capacity - Struck | 35.20 yd³ |
