Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
16 data points
Operating Specifications
| Fuel Capacity | 158.6 gal |
|---|---|
| Tire Size | 29.5x29 2 ** Radials |
Engine
| Engine Model | 3408E HEUI |
|---|---|
| Gross Power | 490.0 hp |
Weights
| Total Empty | 92,170 lb |
|---|---|
| Total Loaded | 180,370 lb |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Overall Length | 444 in |
| Overall Width | 126 in |
| Overall Height | 114 in |
| Dump Height | 106 in |
Transmission
| Max Speed | 29.9 mph |
|---|---|
| Number of Forward Gears | 8 |
| Number of Reverse Gears | 2 |
Dump
| Rated Payload | 88,000 lb |
|---|---|
| Capacity - Heaped | 24.11 yd³ |
