Caterpillar
BOMAG
CR 662 RM
Asphalt Paver
37 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Maximum Paving Speed | 2.8 mph |
|---|---|
| Maximum Throughput Capacity | 1766 ton(US)/h |
| Maximum Travel Speed | 12.0 mph |
| Inside Turn Radius | 54 in |
| Maximum Paving Speed - With Tamper Bar Screed | 0.9 mph |
Engine
| Engine Model | Cat C7.1 |
|---|---|
| Gross Power | — |
Weights
| Operating weight with SE60 FM | 42,620 lb |
|---|---|
| Operating weight with SE60 V | 42,360 lb |
| Operating weight with SE60 V XW | 43,848 lb |
| Shipping Weight - Paver Only | 34,228 lb |
Dimensions
| Transport Width | 143 in |
|---|---|
| Transport Height | 118 in |
| Overall Height | 148 in |
| Transport Length | 251 in |
| Operating Length | 268 in |
| Operating Width | 130 in |
| Paving Range with SE60 V | 118 – 301 in |
| Paving Range with SE60 FM | 118 – 307 in |
| Paving Range with SE60 VT XW | 118 – 236 in |
| Paving Range with SE60 V XW | 118 – 295 in |
Service Refill Capacities
| Hydraulic Oil Tank | 58.0 gal |
|---|---|
| Fuel Tank Capacity | — |
| DEF Tank | 5.0 gal |
| Cooling System - Total | 12.0 gal |
| Washdown Spray Tank | 7.9 gal |
