Caterpillar
Dynapac
F8C
Asphalt Paver
13 specifications
Caterpillar
AP1050
- Operating Weight w/ Screed
- 38,801 lb
- Paving Width - max
- 360 in
- Gross Power
- 145.0 hp
- Length w/ Screed
- 256 in
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight w/ Screed | 38,801 lb |
|---|---|
| Operating Weight w/o Screed | 35,801 lb |
| Fuel Capacity | 60.9 gal |
| Hydraulic System Fluid Capacity | 39.7 gal |
| Cooling System Fluid Capacity | 7.5 gal |
Engine
| Engine Model | 3116 Turbo |
|---|---|
| Displacement | 403 in³ |
| Gross Power | 145.0 hp |
| Aspiration | turbo |
Dimensions
| Length of Track on Ground | 121 in |
|---|---|
| Transport Width | 120 in |
| Transport Height | 107 in |
| Track Width | 14 in |
| Length w/ Screed | 256 in |
| Width w/ Hopper Open | 131 in |
Hopper/Paver
| Paving Width - max | 360 in |
|---|---|
| Paving Speed - max | 2.1 mph |
| Hopper Capacity | 8 lb |
| Travel Speed - max | 5.0 mph |
| Auger Diameter | 16 in |
