Caterpillar
Roadtec Astec
RP-175
Asphalt Paver
21 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Maximum Paving Speed | 2.3 mph |
|---|---|
| Maximum Throughput Capacity | 1100 ton(US)/h |
| Maximum Travel Speed | 7.0 mph |
Engine
| Engine Model (1) | Cat C4.4 |
|---|---|
| Engine Power (1) | 148.0 hp |
Weights
| Operating weight with SE47 FM | 33,689 lb |
|---|---|
| Operating weight with SE47 V | 33,448 lb |
| Shipping Weight - Paver Only | 26,993 lb |
Dimensions
| Transport Width | 102 in |
|---|---|
| Overall Height | 129 in |
| Transport Length | 222 in |
| Operating Length | 231 in |
| Operating Width | 129 in |
| Paving Range with SE47 FM | 94 – 240 in |
| Paving Range with SE47 V | 94 – 244 in |
| Truck Entry Height | 22 in |
Service Refill Capacities
| Hydraulic Oil Tank | 32.0 gal |
|---|---|
| DEF Tank | 5.0 gal |
| Cooling System - Total | 6.3 gal |
| Washdown Spray Tank | 8.5 gal |
| Fuel Tank | 53.0 gal |
