Caterpillar
BOMAG
CR 662 RM
Asphalt Paver
37 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Maximum Paving Speed | 2.8 mph |
|---|---|
| Maximum Throughput Capacity | 1433 ton(US)/h |
| Maximum Travel Speed | 10.0 mph |
| Inside Turn Radius | 54 in |
Engine
| Engine Model | Cat C4.4 |
|---|---|
| Gross Power | — |
Weights
| Operating weight with SE60 FM | 38,316 lb |
|---|---|
| Operating weight with SE60 V | 38,056 lb |
| Operating weight with SE47 FM | 36,716 lb |
| Operating weight with SE50 V | 37,754 lb |
| Shipping Weight - Paver Only | 29,391 lb |
Dimensions
| Transport Width | 118 in |
|---|---|
| Transport Height | 119 in |
| Overall Height | 150 in |
| Transport Length | 251 in |
| Operating Length | 261 in |
| Operating Width | 130 in |
| Paving Range with SE60 FM | 118 – 307 in |
| Paving Range with SE60 V | 118 – 295 in |
| Paving Range with SE47 FM | 96 – 244 in |
| Paving Range with SE50 V | 100 – 256 in |
Service Refill Capacities
| Hydraulic Oil Tank | 58.0 gal |
|---|---|
| Fuel Tank Capacity | 73.0 gal |
| DEF Tank | 5.0 gal |
| Cooling System - Total | 8.0 gal |
| Washdown Spray Tank | 7.9 gal |
