Caterpillar
Roadtec Astec
RP-175
Asphalt Paver
21 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight w/o Screed | 32,695 lb |
|---|---|
| Fuel Capacity | 70.1 gal |
| Hydraulic System Fluid Capacity | 50.0 gal |
| Cooling System Fluid Capacity | 9.8 gal |
Engine
| Engine Model | 3116T |
|---|---|
| Displacement | 403 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 154.0 hp |
| Number of Cylinders | 6 |
Dimensions
| Wheelbase | 101 in |
|---|---|
| Transport Width | 132 in |
| Transport Height | 109 in |
| Tire Size | Front 16x22 Rear 18.00x25-16 |
| Length w/ Screed | 268 in |
Hopper/Paver
| Paving Width - max | 288 in |
|---|---|
| Paving Speed - max | 2.8 mph |
| Hopper Capacity | 8 lb |
| Travel Speed - max | 10.0 mph |
| Auger Diameter | 16 in |
