Caterpillar
Roadtec Astec
RP-175
Asphalt Paver
21 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight w/o Screed | 34,304 lb |
|---|---|
| Fuel Capacity | 60.0 gal |
| Hydraulic System Fluid Capacity | 40.0 gal |
| Cooling System Fluid Capacity | 8.4 gal |
Engine
| Engine Model | 3116TA |
|---|---|
| Displacement | 403 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 174.0 hp |
| Number of Cylinders | 6 |
Dimensions
| Length of Track on Ground | 108 in |
|---|---|
| Transport Width | 120 in |
| Transport Height | 109 in |
| Track Width | 14 in |
| Length w/ Screed | 259 in |
Hopper/Paver
| Paving Width - max | 360 in |
|---|---|
| Paving Speed - max | 2.4 mph |
| Hopper Capacity | 8 lb |
| Travel Speed - max | 5.0 mph |
| Auger Diameter | 18 in |
