Caterpillar
BOMAG
BW 5A S (4-6ton)
Smooth Drum Roller
22 specifications
1 / 5
Image 1 of 5
Specifications
17 data points
Operating Specifications
| Operating Weight | 20,750 lb |
|---|---|
| Max Speed | 12.4 mph |
| Fuel Capacity | 55.0 gal |
| Hydraulic System Fluid Capacity | 14.6 gal |
Engine
| Engine Model | 3054 DINA |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 80.0 hp |
| Number of Cylinders | 4 |
Dimensions
| Height - Top of Cab | 119 in |
|---|---|
| Wheelbase | 10 in |
| Overall Length | 14 in |
| Drum Diameter - Front | 48 in |
Tires & Wheels
| Tires | 13/80-20 |
|---|
Drum
| Drum Width | 67 in |
|---|---|
| Drum Diameter | 47 in |
| Centrifugal Force - High | 17,757 lb |
Comparable machines
Other smooth drum rollers in a similar weight class.
