Caterpillar
Liebherr
RL64
Crawler Dozer
50 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 211,304 lb |
|---|---|
| Fuel Capacity | 393.7 gal |
| Hydraulic Fluid Capacity | 44.7 gal |
Engine
| Engine Model | 3508 |
|---|---|
| Displacement | 2,105 in³ |
| Gross Power | 770.0 hp |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 161.2 gal/min |
|---|---|
| Relief Valve Pressure | 3,300 psi |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Height - Top of Cab | 180 in |
| Length of Track on Ground | 175 in |
| Width Over Tracks | 150 in |
| Length w/ Blade | 331 in |
| Length w/o Blade | 244 in |
Transmission
| Max Speed - Forward | 7.3 mph |
|---|---|
| Max Speed - Reverse | 8.8 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 22 psi |
|---|---|
| Track Gauge | 114 in |
| Number of Track Rollers per Side | 8 |
| Standard Shoe Size | 28 in |
| Ground Contact Area | 9,796 in³ |
Standard Blade
| Width | 221 in |
|---|---|
| Height | 91 in |
| Capacity | 33.50 yd³ |
